Turbo pour Audi A4 A6 Skoda Exquise Vw Passat 1.9 Tdi 101 /110/ 115 Ps 454231 neu

Please confirm your old turbo part number matches up with one of the part numbers above* Professional installation is highly recommended (No Instruction Included)* For any needs please contact us

Comment identifier votre turbocompresseur :

Si vous n'êtes pas sûr de la compatibilité de votre ancien turbo, veuillez nous indiquer ces informations :
1 . Les informations de code OEM de votre plaque signalétique d'origine turbo
2 . Le code moteur et KW, HP, année for votre voiture
3 . Les photos de votre turbo complet
4 . Veuillez noter que le numéro d'enregistrement ne peut pas identifier votre turbocompresseur

Application:

Motorcode: AHH / AFN / AVB / ATJ / AJM

for Audi A4 1.9 TDI (B5/8D2)  1997-2000 81 KW/110 PS  AFN/AVG
for Audi A4 1.9 TDI (B5/8D2)  1997-2001 66Kw//90ps AHH
for Audi A4 1.9 TDI (B5/8D2)  1998-2001 85 KW / 115 PS ATJ/AJM
for Audi A4 1.9 TDI (B6) 2001-2005 74 KW / 101 PS  AVB
for Audi A6 1.9 TDI (C5) 1997-2001 81 KW / 110 PS  AFN/AVG
for Audi A6 1.9 TDI (C5) 1998-2001 85 KW / 115 PS  AJM\

for Skoda Superb I（B5 3U) 1.9 TDI 2001-2005 74 KW / 101 PS  AVB

for VW Passat B5 1.9 TDI 1997-2000 81 KW / 110 PS AFN/AVG
for VW Passat B5 1.9 TDI 1998-2000 66KW/90 PS AHH
for VW Passat B5 1.9 TDI 1998-2005 74 KW / 101 PS AVB
for VW Passat B5 1.9 TDI 1998-2005 85 KW / 115 PS AJM/ATJ

OEM Number:

028145702H, 028145702HV, 028145702HX, 028145702R，

028145702RV, 028145702RX, 038145702L, 038145702LV,

038145702LX, 28145702RV500, 028145702HV225

Part Number:

454231-0001, 454231-0002, 454231-0003, 454231-0004,

454231-0005, 454231-0006, 454231-0008, 454231-0007，

454231-7, 454231-0009, 454231-0010, 454231-5001S,

454231-5002S, 454231-5003S, 454231-5005S, 454231-5006S,

454231-5007S, 454231-5008S, 454231-5009S, 454231-5010S,

454231-5012S, 454231-9012S, 4542315013S, 454231-9013S，

454231-0013, 4542310013

Specification:

Turbo Model ：GT1749V (S1), GT1749V(S2)

Engine Code ：AVB, AFN, ATJ, AJM, AHH

Cooled Type： Oil Cooling

Bearing Type: Floating Bearing

Hosepower:  Up to 114 HP

Condition: Brand New

Package size: 26*24*23 cm

Weight: 5740 g

Accessories: You will get exactly as shown in the picture above

1. 100% balancing Test by TURBOTECHNICS  VSR3

2. G3-min-Flow VNT Turbo testing

3.  Advanced Actuator Tester/Programmer

*Product Material
1. Turbine housing ：Ductile iron qt450-10- temperature resistant up to 700℃
2. Steel turbine wheel：K418 alloy -  high  oxidation stability and resistance  up  to 900℃
3. Compressor housing：ZL104 aluminum with lightweight
4. Compressor wheel/blades：Cast aluminium blades – superior air tightness & corrosion resistance

*Product
1. OEM-quality and size with little modification
2. Rich experience in turbo production and own factory
3. Quality assurance
4. High-Speed oil seal ring
5. Strict quality inspection
6. Precision clearance

*All necessary gaskets included for ease of installation

For any other question, please feel free contact us by ebay message
