Maxpeedingrods – Turbocompresseur GT3582 pour Nissan Safari Patrol – Intercooler 600x300x76mm – Pipe Kit 64mm – 600HP max – M10, M14, 2.5"
'/%3E%3C/svg%3E)
Ces articles peuvent vous intéresser !
Comparer à des articles similaires
Souvent achetés ensemble
Informations produit
Description
This turbo is an universal application turbo, some modification may be required based on individual vehicle. The dimension picture is available, please contact us if needed. Please check the details carefully before purchasing.
ApplicationPerfect for all 4/6 cylinder and 2.5L-6.0L engines
Horse Power: Capable of Boosting Horse Power up to 600HP
Cooling Type: Water + Oil
Bearing: Wet Float
Warranty: 2 Years
Oil Inlet: M10*7/16-24
Oil Outlet: M14.1 & 2*M8*1.25
Water: M14*1.5
Wastegate：Ohne Wastegate Specification Compressor Compressor Trim: 57 Compressor Inducer Diameter: 61.5mm Compressor Exducer Diameter: 81.5mm Compressor A/R: 0.7 (Blades Number 6 double) Turbine Exhaust Inlet (Turbo Manifold) Flange: T3 Flange Exhaust Outlet Flange: 4 Bolt Turbine Trim: 84 Turbine Inducer Diameter: 68mm Turbine Exducer Diameter: 62.4mm Turbine A/R: 0.63 (Blades Number 10 double)
Intercooler Turbo Piping Pipe Kit
Pipe Thickness: 1.8mm
Pipe length: 18''
- brand new Never been tried or installed.
-100% quality assurance tested
-Made out of high quality of 6061 aluminum Manual polishing finished
Intercooler
Core Dimension: 600 X 300 X 76 MM
Inlet / outlet size: 3" inch
Thickness: 3" (76mm)
Pipe length: 18''
Pipe Thickness: 1.8mm
Core design: Tube & Fin
Color: Silver
Intercoolers are designed with a tube and fin core which has the highest thermodynamic dissipative process.
100% quality assurance tested
Made out of high quality of 6061 aluminum Manual polishing finished
Package Including
2x 90 Degree Aluminum Pipe 2.5"
2x Straight aluminum pipe 2.5"
2x 135 Degree Aluminum Pipe×2 2.5"
2x U Aluminum Pipe×2 2.5"
6x Straight Silicon Hose 2.5" (Blue )
2x 90 Degree Silicone Hose×2 2.5"(Blue )
16x Clamps 2.5"
1x Turbo and gaskets
600x300x76mm Intercooler
Notice
* Please check the specifications carefully before bidding. If you are not sure about these information, please feel free to contact us
* This is universal application turbo, so modification might be required for some vehicles * Professional installation is highly recommended (No Instruction Included)
Caractéristiques
- MarqueMAXPEEDINGRODS
- MatièresAluminium
- Réf. ManoManoME92798431
- MMID928492650012
- Réf. fabricantGG250513A169
- EAN6923487000094
