Disjoncteur Siemens 3RV1011-1KA10 3 NO (T) Plage de réglage (courant): 9 - 12 A Tension de contact (max.): 690 V/AC (l
Ces articles peuvent vous intéresser !
Comparer à des articles similaires
Souvent achetés ensemble
Informations produit
Description
Informations techniques
Connexion (composants) : borne à vis
Dimensions (relais) : S00
Dimensions produit, hauteur : 90 mm
Dimensions produit, largeur : 45 mm
Dimensions produit, profondeur : 81 mm
Indice de protection : IP20
Nombre de pôles (LOV) : 3 pôles
Plage de réglage du courant (min.) : 9 A
Tension de contact (max.) : 690 V/AC
Type de contact (LOV) : 3 NO (T)
Valeur du courant d'appel (max.) : 12 A
Circuit breaker size S00 for motor protection, CLASS 10 A-release 9...12 A N-release 156 A Screw terminal Standard switching capacity Circuit breaker SIRIUS 3RV1 For motor protection for the reliable shutdown in the event of a short-circuit and for protecting the loads and system against overload, and for safe isolation of the system from the network. Thanks to their low heat loss, the compact and climate-resistant circuit breakers are optimized for use in load feeders, and also for IE3/IE4 motors, of course, and equally for the switching of direct current. Worldwide approvals (e.g. IEC and UL/CSA) and applications in hazardous areas (ATEX or IEC Ex) are a matter of course. Device versions are available for motor protection, as main and EMERGENCY OFF switches and for use in IT networks. They are available with screw terminals and optionally with an integrated auxiliary switch. The comprehensive range of accessories, such as auxiliary switches, auxiliary releases etc. is standardized for all sizes. The use of different energy infeed options, such as the associated SIRIUS 3RV29 infeed system, considerably reduces the main circuit wiring. Simple, efficient and always up to date - SIRIUS modular system.
Configuration requise
- null
- null
Caractéristiques
- MarqueSIEMENS
- Longueur8.1 cm
- Largeur45 mm
- Hauteur54 mm
- Poids278 g
Impact environnemental
- OrigineFabriqué en Allemagne
Questions fréquentes
La plage de réglage du courant pour cet appareil est comprise entre 9 et 12 A, ce qui permet de l'adapter à différents besoins de protection moteur.
Oui, ce dispositif est conforme aux normes CEI 947 et VDE, garantissant sa fiabilité et sa sécurité dans les installations électriques.
Le mode de fixation recommandé pour cet équipement est une installation avec vis, assurant une fixation stable et sécurisée.
