BERM/Belme REX-C700FK02-MAN Digital Display Intelligent High-Precision Temperature Controller Electronic Temperature Gauge 100V-240V
Vous achetez pour votre entreprise ?
Tarifs négociés HT jusqu'à -20%
Ces articles peuvent vous intéresser !
Comparer à des articles similaires
Souvent achetés ensemble
Informations produit
Description
1、VARIETY OF USES: Our temperature controller has a simple detachable shell design, which is convenient for maintenance, safe and reliable.
2、POWERFUL INPUT FUNCTION: Thermostat controller with solid state output, relay output, two output functions, powerful output function.
3、HIGH ACCURACY: The core of high accuracy chip temperature controller, accurate temperature control, high sensitivity.
4、MULTIPLE INPUT WAYS: The intelligent temperature controller has PID control adjustment, alarm switch, and multiple input ways.
5、RUGGED CONSTRUCTION: Made of high quality ABS, not easy to damage, long service life, can be used for a long time.
Item Type: Temperature Controller
Material: ABS
Model: REX-C700FK02-M*AN
Purpose: Temperature control of industry, building, plant and equipment
Working Voltage: 100V-240V 50HZ/60HZ
Working Power Supply: 220V~±10%50HZ
Power Consumption: 4W
Panel Size: Approx. 72x72mm / 2.8x2.8in (unit: mm/MM)
Installation Hole Size: Approx. 68x68mm / 2.7x2.7in (unit: mm/MM) with PID self setting function
Input Signal: K/J/S/PT100, etc. (the factory setting is K, other input signals can be adjusted by referring to the manual)
Temperature Range: 0-1372℃ (factory setting is 400°C, the highest can be adjusted to 1372℃)
Main Control Output: Relay output (RELAY/M)
Alarm Range: Free setting of full range
Measurement Error: 1%+1 word, 0.5%±1 word, 0.2%±1 word, three gears
Additional Cold Junction Compensation Error: Within the range of 0~50℃, ≤±2℃, temperature coefficient ≤0.05%/℃
Relay Output Contact Capacity: 3A/220V, resistive or specified
Thyristor Trigger Signal: 15/40μS or rated 100mA, instantaneous IA (self triggering)
Solid State Relay Output Signal: 15±3V/3 0mA
Working Environment: 0~50℃, relative humidity 35%-85%RH, non corrosive and no strong electromagnetic field radiation
1 x Temperature Controller
2 x Fixing Clip
1 x Manual
Caractéristiques
- MarqueSABE
- ConnectéNon
- CouleurMulticouleur
- Écran rétroéclairéOui
- MatièresABS
- Quantité par pack1
- Type d'équipement compatibleChaudière
- Type de thermostatÉlectronique
- Réf. ManoManoME236971698
- MMID895613311137
- Réf. fabricantSABE0812-FX16150
- EAN7772992942097
