Entretoises 5x114.3 épaisseur 25mm CB60.1 Suzuki Grand Vitara 2, SX4 - 2 pièces

Wheel spacers with a thickness of 25 mm, with a bolt pattern of 5x114.3 mm and a center bore of 60.1 mm, equipped with a centering ring.

These spacers were precisely made from anodized aluminum 6061 in T6 condition, which provides significantly better strength properties compared to the commonly used PA21 alloy. They are equipped with hardened steel studs with thread M12x1.25.

The price applies to a set of 2 spacers.

Fits:

Dimensions:

• Thickness: 25 mm
• Number of bolts: 5
• Bolt pattern: 114.3 mm
• Center bore diameter: 60.1 mm
• Thread: M12x1.25

Proper installation should be performed by a qualified specialist with appropriate knowledge about this type of products.

The following points constitute only general guidelines:

1. For proper and safe installation, a torque wrench is required (do not use pneumatic tools). It is necessary to thoroughly remove any corrosion from the hub and brake disc using sandpaper, wire brush or cleaning disc to ensure proper seating of the spacer.
2. Make sure that the spacer fits perfectly to the vehicle hub and the wheel to the spacer surface.
3. Make sure that the studs of the spacer have the same thread pitch as the original vehicle studs. Otherwise, it will be necessary to use additional nuts.
4. The original vehicle studs may be longer than the thickness of the spacer. In such a case, there are two possibilities:
   • Cut the original studs or replace them with shorter ones.
   • If the wheels have appropriate recesses between the mounting holes, it may not be necessary to shorten them.
5. Do not mount wheels on spacers if the original studs touch the back of the wheel. Make sure that the wheel fits completely to the spacer surface.
