Universal Wireless Remote Control Switch DC12V 1CH Relay Receiver Module RF mitter 433Mhz Smart
Dont éco-participation : 0,01 € TTC
15 € offerts dès 250 €
avec le code
avec le code
Vous achetez pour votre entreprise ?
Tarifs négociés HT jusqu'à -20%
Produit similaire livré par
Télécommande cardin s449 qz/2p
18,00 €
3
Vendu par Bubbly SHOP et 1 autre marchand
Ces articles peuvent vous intéresser !
Comparer à des articles similaires
Souvent achetés ensemble
Informations produit
Description
Specifications Of The Remote Control: Model Number: KT08-4
Operating RF Frequency: 433MHz. Coded System: 1527 Learning Code.
Working Voltage: DC 3V. Working Current: less than 25mA
mitting Power: 10mW. Wireless Operating Distance: 50m(Free Space).
mission Rate: 50 - 60KHz. Frequency Deviation: +0.2MHz or -0.2MHz.
Technical Data Of Receiver:
Model Number:KR1201A
Input voltage: 12V
Working current: 10A
Maximum load power: 110W
Frequency: 433Mhz
Support encoding format: EV1527
Wiring method: NC COM NO
Working mode: Momentary, Toggle, Latching Time delay (5s ,10s ,15s )
Wiring diagram :
+V : 12V + input
- V: 12V - input
NO: Output , normal open
COM:Output , common
NC: Output , normal close
Wireless Communication:RF
Item Type:Switches
Switch Type:Remote Control
color:Black
Material:plastic
Package Contents:
1 x receiver switch
1 x remote control
Only the above package content, other products are not included.
Note: Light shooting and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.
Caractéristiques
- MarqueSLOWMOOSE
- Quantité par pack1
- CouleurNoir
- Largeur10 cm
- Longueur15 cm
- Poids200 g
- Tension électrique12 V
- Type de composant électroniqueBobine
- Réf. ManoManoME218963424
- MMID450257094777
- Réf. fabricant4203540094171
- EAN4203540094171
